The Hucktainer® fastener is designed to meet the special needs of FRP fabrication. These Huck fasteners install with a consistent pressure that reduces the potential for crushing or crazing FRP panels.
DIMENSIONAL DATA
Back to Top
TENSILE STRENGTH DATA
Grip Number |
Grip Range |
|
|
|
|
|
min |
max |
Hole Size |
A |
B |
C |
D |
-9 |
.500 |
.625 |
.405-.421 |
.624 |
2.244 |
** |
.015 |
-10 |
.562 |
.687 |
.405-.421 |
.624 |
2.232 |
.090 |
.015 |
-11 |
.625 |
.750 |
.405-.421 |
.687 |
2.295 |
.090 |
.015 |
-12 |
.687 |
.812 |
.405-.421 |
.749 |
2.357 |
.220 |
.145 |
-13 |
.750 |
.875 |
.405-.421 |
.812 |
2.420 |
.220 |
.145 |
-14 |
.812 |
.937 |
.405-.421 |
.874 |
2.482 |
.345 |
.270 |
-15 |
.875 |
1.000 |
.405-.421 |
.937 |
2.545 |
.345 |
.270 |
-16 |
.937 |
1.062 |
.405-.421 |
.999 |
2.607 |
.470 |
.395 |
-17 |
1.000 |
1.125 |
.405-.421 |
1.062 |
2.670 |
.532 |
.457 |
-18 |
1.062 |
1.187 |
.405-.421 |
1.124 |
2.732 |
.595 |
.520 |
-19 |
1.125 |
1.250 |
.405-.421 |
1.187 |
2.795 |
.658 |
.583 |
-20 |
1.187 |
1.312 |
.405-.421 |
1.249 |
2.857 |
.720 |
.645 |
-21 |
1.250 |
1.375 |
.405-.421 |
1.312 |
2.920 |
.782 |
.707 |
-22 |
1.312 |
1.437 |
.405-.421 |
1.374 |
2.982 |
.782 |
.707 |
-23 |
1.375 |
1.500 |
.405-.421 |
1.437 |
3.045 |
.782 |
.707 |
-24 |
1.437 |
1.562 |
.405-.421 |
1.499 |
3.107 |
.782 |
.707 |
-25 |
1.500 |
1.625 |
.405-.421 |
1.562 |
3.170 |
.782 |
.707 |
-26 |
1.562 |
1.687 |
.405-.421 |
1.625 |
2.232 |
.782 |
.707 |
-27 |
1.625 |
1.750 |
.405-.421 |
1.687 |
3.295 |
.782 |
.707 |
-28 |
1.687 |
1.812 |
.405-.421 |
1.750 |
3.357 |
.782 |
.707 |
-29 |
1.750 |
1.875 |
.405-.421 |
1.812 |
3.420 |
.782 |
.707 |
-30 |
1.812 |
1.937 |
.405-.421 |
1.875 |
3.482 |
.782 |
NA |
|
|
|
|
|
|
|
|
NOTE: Only wide bearing pin HLPE ( ) and/or wide bearing sleeve HLPS should be used
directly against FRP. Consult factory for stock statusminimums may apply. Consult factory
for other head styles and grip configurations.
Contact your HUCK representative for head styles, grips, and configurations not shown.
